In urmatorul post ne uitam si la alt sistem de operare specific echipamentelor Juniper si anume JunOS. Eu consider ca acest sistem de operare este foarte potrivit intr-un cadru de lucru in care greselile de config pot fi corectate foarte usor prin revenirea la o configuratie anterioara cu ajutorul unei singure comenzi, rollback. Un alt avantaj este cel reprezentat de utilizarea comenzii commit, astfel incat nu avem configuratii intermediare/incomplete.
Elementele cheie sunt:
- P2 si PE2 ruleaza JunOS
- P1 si PE1 ruleaza IOS
- intre PE1 si PE2 avem o sesiune iBGP VPNv4
- pe fiecare PE am definit doua VRF-uri (VPN-A si VPN-B) cu acelasi plan de adresare, pentru a verifica izolarea corecta atat din control-plane cat si din data-plane
Topologie
Config routere P
P1interface Loopback0ip address 11.11.11.11 255.255.255.255 !Fa0/0.5 - leg catre PE1 interface FastEthernet0/0.5 encapsulation dot1Q 5 ip address 172.16.5.1 255.255.255.0 ip router isis AS100 mpls ip !Fa0/0.10 - leg catre P2 interface FastEthernet0/0.10 encapsulation dot1Q 10 ip address 172.16.10.2 255.255.255.0 ip router isis AS100 mpls ip mpls ldp router-id Loopback0 force router isis AS100 is-type level-2-only net 49.0001.0110.1101.1011.00 passive-interface Loopback0 |
P2interfaces {em0 { vlan-tagging; /*unit 10 - leg catre P1*/ unit 10 { vlan-id 10; family inet { address 172.16.10.1/24; } family iso; family mpls; } /*unit 20 - leg catre PE2*/ unit 20 { vlan-id 20; family inet { address 172.16.20.1/24; } family iso; family mpls; } } lo0 { unit 1 { family inet { address 1.1.1.0/32; } family iso { address 49.0001.0010.0100.1001.00; } family mpls; } } } protocols { mpls { interface em0.10; interface em0.20; } isis { level 1 disable; interface em0.10; interface em0.20; interface lo0.1 { passive; } } ldp { interface em0.10; interface em0.20; } } |
Config routere PE
PE1ip vrf VPN-Ard 100:1 route-target export 100:1 route-target import 100:1 ip vrf VPN-B rd 100:2 route-target export 100:2 route-target import 100:2 interface Loopback0 ip address 22.22.22.22 255.255.255.255 interface Loopback10 ip vrf forwarding VPN-A ip address 10.1.1.1 255.255.255.255 interface Loopback20 ip vrf forwarding VPN-B ip address 10.1.1.1 255.255.255.255 !Fa0/0.5 - leg catre P1 interface FastEthernet0/0.5 encapsulation dot1Q 5 ip address 172.16.5.2 255.255.255.0 ip router isis AS100 mpls ip router isis AS100 net 49.0001.0220.2202.2022.00 passive-interface Loopback0 router bgp 100 no bgp default ipv4-unicast !sesiune iBGP VPNv4 cu PE2 neighbor 2.2.2.2 remote-as 100 neighbor 2.2.2.2 update-source Loopback0 address-family vpnv4 neighbor 2.2.2.2 activate neighbor 2.2.2.2 send-community extended exit-address-family address-family ipv4 vrf VPN-B redistribute connected exit-address-family address-family ipv4 vrf VPN-A redistribute connected exit-address-family |
PE2interfaces {em0 { vlan-tagging; unit 20 { vlan-id 20; family inet { address 172.16.20.2/24; } family iso; family mpls; } } lo0 { unit 1 { family inet { address 2.2.2.2/32; } family iso { address 49.0001.0020.0200.2002.00; } } unit 10 { family inet { address 10.2.2.2/32; } } unit 20 { family inet { address 10.2.2.2/32; } } } } protocols { mpls { interface em0.20; } bgp { group iBGP { local-address 2.2.2.2; peer-as 100; local-as 100; neighbor 22.22.22.22 { family inet-vpn { unicast; } } } } isis { level 1 disable; interface em0.20; interface lo0.1; } ldp { interface em0.20; interface lo0.1; } } routing-instances { VPN-A { instance-type vrf; interface lo0.10; route-distinguisher 100:1; vrf-target { import target:100:1; export target:100:1; } vrf-table-label; } VPN-B { instance-type vrf; interface lo0.20; route-distinguisher 100:2; vrf-target { import target:100:2; export target:100:2; } vrf-table-label; } } |
Pentru a testa puteti folosi comenzile ping 10.1.1.1 routing-instance VPN-A si ping 10.1.1.1 routing-instance VPN-B de pe routerul PE2.
